Introducing the Cluster API plugin for Headlamp

Overview of the Cluster API Plugin for Headlamp

Headlamp is an open-source, extensible Kubernetes SIG UI project that enables users to explore, manage, and debug cluster resources directly from a browser. Cluster API (CAPI) is a Kubernetes sub-project that introduces declarative, Kubernetes-style APIs for managing the lifecycle of Kubernetes clusters. Historically, managing Cluster API resources has required raw kubectl commands and a deep understanding of ownership hierarchies. The Headlamp Cluster API plugin addresses these challenges by providing a visual interface that simplifies operations and debugging for platform teams.

Key Features of the Plugin

The plugin introduces a dedicated Cluster API section within Headlamp, offering full visibility into core CAPI resources through consistent list and detail views. Some of the key features include:

• Cluster Overview: View live control plane and worker replica status for clusters.
• Machine Visibility: Inspect MachineDeployments, MachineSets, Machines, and MachinePools with status and conditions.
• Cluster API Dashboard: A centralized view of Cluster API resource health, active condition issues, provider information, and remediation guidance.
• Control Plane Monitoring: Track KubeadmControlPlane replicas, versions, and associated Machines.
• Scale from the UI: Adjust replica counts for MachineDeployments and MachineSets directly from Headlamp.
• Owned Resource Hierarchy: Trace relationships between clusters, deployments, sets, and machines.
• KubeadmConfig Inspection: View bootstrap configurations, files, kubelet arguments, and join/init settings.
• Topology Awareness: Automatically detect and label ClusterClass-managed resources.
• Map View: Visualize relationships between Cluster, control plane, and worker resources.
• Dynamic API Versioning: Supports both v1beta1 and v1beta2 Cluster API versions.
• Prometheus Metrics: View live metrics from the Headlamp Prometheus plugin inline on Cluster API resource detail pages.

Plugin Architecture and Integration

The plugin integrates with the Headlamp Prometheus plugin to surface metrics directly inside Cluster API resource detail pages. When the Prometheus plugin is installed and configured, metrics are embedded inline on the detail pages for Clusters, MachineDeployments, MachineSets, and Machines. This integration allows users to view resource health and performance data alongside status conditions and ownership relationships without switching to a separate dashboard.

Development and Community Involvement

The plugin was developed as part of the CNCF LFX Mentorship program under the Headlamp project. This initiative provided an opportunity to work closely with the Headlamp community while building features to improve the Cluster API management experience. The development process involved discussions with mentors and community members to shape the plugin's direction, improve the user experience, and prioritize features most useful to platform teams.

Getting Started

Users can find installation and usage instructions in the plugins/cluster-api/README.md file. The plugin is currently in an Alpha release, and community feedback directly shapes its future development. Users are encouraged to report bugs, request features, and contribute pull requests to help improve the plugin.

For further questions and discussions, users can join the Kubernetes Slack #headlamp channel.
